Miboxer SPIR3 - 3 in 1 SPI LED Controller (2.4GHz)
Key Features
- 3-in-1 Functionality: Supports Single Color, RGB, and RGBW Pixel LED strips.
- Pixel Dots: Capacity for Single Color (2048), RGB (1536), RGBW (1024) pixel dots.
- Output Signal: SPI (TTL) at 800Kbps.
-
Configuration Options:
- Set the color and adjust the strip length.
- Schedule ON/OFF times and preset colors.
- Select output modes (Single Color, RGB, RGBW) via the "SET" button.
- Control ON/OFF functions and switch between dynamic modes.
- Dynamic Modes: Offers a total of 20 dynamic lighting modes with the ability to customize colors.
- DND Function: Includes a Do Not Disturb function, useful in areas prone to power outages to conserve energy.
The SPIR3 controller combines versatility and robust performance, making it an ideal choice for managing Pixel LED strips with precision and ease.
Compatible chips (controller doesn't need to set chip types)
TM1809, TM1804, TM1812, SK6813, UCS1903, UCS1909, UCS1912, UCS2903, UCS2909, UCS2912, WS2811, WS2812, WS2813, WS2815，SK6812(RGBW), WS2813(RGBW), WS2814(RGBW)
The SPIR3 controller is specially crafted for Pixel LED strips, leveraging advanced 2.4GHz wireless transmission technology for high-speed transmission and robust anti-interference capabilities, ensuring a stable signal. When paired with the C6 or B6 remote, it allows users to adjust modes, colors, brightness, and ON/OFF schedules, and edit dynamic lighting features effortlessly.
Manual Download:
